▪ RF Transmitter ▪ Power Input : DC 5V ▪ Power Current : 60 mA ▪ Power Output : 10mW ▪ Video Output : 1Vp-p ▪ Audio Output : 1Vp-p Max ▪ Frequency 2414, 2432, 2450, 2468MHz ▪ Sub Carrier :6.5 MHz ▪ Dimension :9 x 19mm

▪ RF TRANSMITTER ▪ Power ootput :(DB/MW) 0 DB=1MW ▪ Modulate:FM ▪ Frequency: 50mhz-1000MHz (977MHz) ▪ power intput: DC 3.3V (DC 2~5V) ▪ power consuption: 5mA ▪ wideo intput: 1Vpp ▪ weight: 2g ▪ Diamension: 6.4mm(D)x 2.8mm

RF TRANSMITTER Power ootput :(DB/MW) 0 DB=1MW Modulate:FM Frequency:50mhz-1000mhz power intput: 3-6V power consuption: 5mA wideo intput: 1Vpp weight: 2g Diamension: 6.4mm(D)x2.8mm

Use with UCD-210, application of video wireless WiFi transfer to "iPAD , iPhone, android tablet, android phone, PC " ▪ 1T1R mode WAN WPS ▪ Wireless LAN 1T1R mode ▪ Date rate 802.11n: up to 300Mbps ▪ 802.11b: 11Mbps ▪ 802.11g: 54 Mbps ▪ Resolution: 640 x 480 up to 25fps, 320 x 240 up to 30fps, 160 x 120 up to 30fps, 1280x720, 1280x960, 1280x1024 ▪ Support windows XP, WIN 7, iPad, OSX android (Samba server support need samba client APP, audio support(RTSP) ▪ PCB Size Dimension(mm): 25(w) x 35(L) x 13(H) ▪ Power1: DC5V(1.2A) connector: micro USB ▪ Power2: DC 3.1~4.2V Li-ion battery

"Using with UCD-210, application of video wireless Wifi transfer to " ipad, iphone, android tablet, android phone, pc" ▪ RJ45 port x 2 (1LAN, 1WAN), USB x 1 ▪ 1LAN/1 WAN WPS ▪ Antenna internal PIFA 2dBi antenna design ▪ Wireless LAN 2T2R mode ▪ Date rate 802.11n: up to 300 Mbps ▪ 802.11b: 11 Mbps ▪ 802.11g: 54 Mbps ▪ Resolution: 640 x 480 up to 25fps, 320 x 240 up to 30fps, 160 x 120 up to 30fps, 1280x720, 1280x960, 1280x1024 ▪ Support windows XP, WIN 7, ipad, OSX, android (Samba server support need samba client APP) Audio support (RTSP) ▪ Dimension(mm): 80(w) x 49(L) x 13(H) ▪ Power: DC5 V(1.2A) /connector: min USB

Model: MST-AB2000 ▪ RF Transmitter ▪ Power Input: DC 12V ▪ Power Current: 900 mA ▪ Power Output: 2W ▪ Video Output: 1Vp-p Composite Video ▪ Audio Output: 2Vp-p Max ▪ Frequency:2413,2432,2451,2470 MHz ▪ Sub Carrier: 5.5 MHz ▪ Dimension: 102(W)x90(L)x63.4(H)mm   Model: MST-BB2000 ▪ RF Transmitter ▪ Power Input: DC 12V ▪ Power Current: 900 mA ▪ Power Output: 2W ▪ Video Output: 1Vp-p Composite Video ▪ Audio Output: 2Vp-p Max ▪ Frequency: 1080,1120,1160,1200 MHz ▪ Sub Carrier: 5.5 MHz ▪ Dimension: 102(W)x90(L)x63.4(H)mm   Model: MST-AB5000 ▪ RF Transmitter ▪ Power Input: DC 12V ▪ Power Current: 2A (MAX) ▪ Power Output: 5W ▪ Video Output: 1Vp-p Composite Video ▪ Audio Output: 2Vp-p Max ▪ Frequency: 2413,2432,2451,2470 MHz ▪ Sub Carrier: 5.5 MHz ▪ Dimension: 97(W)x90(L)x60(H)mm   Model: MST-BB5000 ▪ RF Transmitter ▪ Power Input: DC 12V ▪ Power Current: 2A (MAX) ▪ Power Output : 5W ▪ Video Output: 1Vp-p Composite Video ▪ Audio Output: 2Vp-p Max ▪ Frequency: 1080,1120,1160,1200 MHz ▪ Sub Carrier: 5.5 MHz ▪ Dimension: 97(W)x90(L)x60(H)mm

All type:TXT-AB2 , TXT-AB6 , TXT-BB1 , TXT-BB5 ▪ Power Output :100mW , 200mW , 500mW , 600mW ▪ Frequency 1200 ~ 2400MHz ▪ Dimension:55x70X15mm(100 , 200mW) ; 55x86x20mm(500 , 600mW) ▪ Rechargeable Battery

▪ Power Output 200mW 　 ▪ Video Input 1Vp-p Composite Video ▪ Audio Input 2Vp-p Max ▪ Frequency:2413,2432,2451,2470 MHz ▪ AUDIO SUB CARRIER 5.5MHz

▪ Power Output 30mW　 ▪ Video Input 1Vp-p Composite Video ▪ Audio Input 2Vp-p Max ▪ Frequency:2413,2432,2451,2470 MHz

▪ Power Output 500mW　 ▪ Video Input 1Vp-p Composite Video ▪ Audio Input 2Vp-p Max ▪ Frequency:2413,2432,2451,2470 MHz ▪ AUDIO SUB CARRIER 5.5MHz

▪ RF TRANSMITTER Frequency 1394 MHz ▪ Power output 500 mW ▪ Video Input 1Vp-p Composite Video ▪ Audio Input 2Vp-p Max ▪ Power Current 280mA ▪ Frequency 1394 MHz ▪ Dimension 49 X 26 X 8.2 mm

▪ RF TRANSMITTER ▪ Frequency 1394 MHz ▪ Power output 50 mW ▪ Power Current 180mA ▪ Video Output 1Vp-p Composite Video ▪ Audio Output 2Vp-p Max ▪ Dimension :9.2 x 37.3mm

▪ Power Output 500mW　 ▪ Video Input 1Vp-p Composite Video ▪ Audio Input 2Vp-p Max ▪ Frequency: 1080,1120,1160,1200 MHz

▪ Power Output 1mW　 ▪ Video Input 1Vp-p Composite Video 　 ▪ Frequency: Adustable 900- 2400MHz(NON-PLL) ▪ Dimension(mm) : 8 ×11mm

▪ 2.4GHZ BAND frequency transmission. ▪ Compact size module, high output power (1Watt). ▪ Highly integrated circuit / High power output (1Watt). ▪ 4 channels D:P switch selectable. ▪ High Reliability / linearity AlGaAs/GaAs FET power Amplifier module. ▪ Using digital phase-Lock-Loop circuit without temperature drifting problem. ▪ Built-in 8V Regulator.

▪ 4 channels slide switch selectable. ▪ Power Input DC 12V ▪ Power Output 2 W ▪ Power Current 850 mA ▪ Video Input 1Vp-p ▪ Audio Input 1Vp-p ▪ Frequency 1080, 1120, 1160, 1200 MHz.

▪ RF Transmitter ▪ Power output 100 mW ▪ Sub carrier 6.5 MHz ▪ Frequency:2414, 2432, 2450, 2468MHz ▪ Power input:DC 5V ▪ Video Output 1Vp-p ▪ Audio Output 2Vp-p ▪ Dimension:15x15mm

▪ RF Transmitter ▪ Power output 10 mW ▪ Sub carrier 6.5 MHz ▪ Frequency:2414, 2432, 2450, 2468MHz ▪ Power input:DC 3.3V ▪ Video Output 1Vp-p ▪ Audio Output 1Vp-p ▪ Dimension:38.1x18.4mm

▪ Resolution input: CVBS: 720x480 /720x576 SDI: 1920x1080P /1280x720P /1920x1080i HDMI: 1920x1080P /1280x720P /1920x1080i ▪ Resolution input: (HD Mode) All of resolution scale down /up into 1280x720P @15fps ▪ Compression: Video: MPEG2 ; Audio: MPEG2 ▪ Operating Temperature: 0 degree C~ 60 degree C ▪ RF connector 5 (Wireless / Wire Mode): 50-ohm BNC connecters , SMA ▪ Bandwidth: 6MHz ▪ FFT: 2K, 4K, 8K ▪ Modulation Constellation: QPSK, 16QAM, 64QAM @ DTMB ▪ Modulator system: DTMB @ 8MHZ ▪ RF Output Level: -12 dBm ▪ MER: 25dB Typically ▪ Power: DC 5V, Power Consumption 6W ▪ Weight: 85g ▪ Dimension(mm): 107 x 108

▪ Frequency Band: 1200MHz(TX-120015) ▪ Frequency Band: 2400MHz(TX-240015) ▪ Available Channel: 8 Ch ▪ Audio Subcarrier: 5.5MHz(TX-120015) ▪ Audio Subcarrier: 6.5MHz(TX-240015) ▪ Operating Voltage: DC 12V ▪ Operating Current: 300~350mA ▪ Trans. Range:0.5W：120m / 1W：200m (Open space) ▪ Transmission Power: 0.5W：27±0.5 dBm / 1W：30±1 dBm ▪ Power Consumption: 3.6W ▪ Operating Temperature: 0~60° ▪ Operating Humidity: 20~80% ▪ Channel Selection: Dip Switch ▪ Antenna Connector: SMA Connector ▪ Frequency Lock Method: Digital Phase Lock Loop ▪ Weight: 17±1g ▪ Dimension: 37.5(L)x27(W)x12.6(H)mm

▪ Frequency Band: 1200MHz(TX-121000) ▪ Frequency Band: 2400MHz(TX-241000) ▪ Available Channel: 8 Ch ▪ Audio Subcarrier: 5.5MHz(TX-121000) ▪ Audio Subcarrier: 6.5MHz(TX-241000) ▪ Operating Voltage: DC 12V ▪ Operating Current: ≦350mA ▪ Trans. Range: 200m (Open space) ▪ Transmission Power: 30±1 dBm ▪ Power Consumption: ≦4.2W ▪ Operating Temperature: 0~60° ▪ Operating Humidity: 20~90% ▪ Channel Selection: Dip Switch ▪ Antenna Connector: SMA Connector ▪ Frequency Lock Method: Digital Phase Lock Loop ▪ Weight: 27±1g ▪ Dimension: 59.8(L)x25(W)x11.3(H)mm

▪ Frequency Band: 1200MHz(TX-120500) ▪ Frequency Band: 2400MHz(TX-240500) ▪ Available Channel: 8 Ch ▪ Audio Subcarrier: 5.5MHz(TX-120500) ▪ Audio Subcarrier: 6.5MHz(TX-240500) ▪ Operating Voltage: DC 5V ▪ Operating Current: ≒500mA ▪ Trans. Range: 120m (Open space) ▪ Transmission Power: 27±0.5 dBm ▪ Power Consumption: ≦2.5W ▪ Operating Temperature: 0~60° ▪ Operating Humidity: 20~90% ▪ Channel Selection: Dip Switch ▪ Antenna Connector: SMA Connector ▪ Frequency Lock Method: Digital Phase Lock Loop ▪ Weight: 10±1g ▪ Dimension: 30*22.5*6.8 mm (L*W*H)
