Hidden Button Screw Camera
UVC Signal 246 Series Only
( PCB and lens are embedded within the button. ) |
|
|---|
|
|
Low Temperature (USB 2.0)
HD-R24631UA-88
• Ø 13 x 2.6 mm |
|
|---|
|
|
|
Advance (USB 2.0)
TD-R24625UA-88
• Ø 18 x 3.6 mm |
|
|---|
|
|
|
|---|
|
|
1/7.25" Color CMOS 2 MP
• Resolution: 1920 x 1080 @ 30 fps
• Pixel Size (µm): 1.116 × 1.116
• Lens: 1.25 mm / F 2.2
• View Angle: 88°
• Up View / Built-In Microphone
• USB cables, up to 1 m long
R24631UA (Ø 1.6 mm) & R24625UA (Ø 0.8 mm)
|
|
|---|
|
|
|
|
|---|
|
|
Microphone
Voice Recorder Card |
|
|---|
|
|
Voice Recorder Card
MS-8000X
• Card Dimensions (mm): 85.7 (W) x 54 (L) x 1.5 (H)
• Card Reader Dimensions (mm): 66 (W) x 66.7 (L) x 12 (H)
• File Format: WAV
• Sampling Rate: 24 KHz
• Bit Rate: 192 Kbps
• File Size: 20 MB / 15 Minutes
• Battery Capacity: 3.7V / 170 mAh, lithium ion battery
• Battery: 3 hrs (recording) / 24+ hrs (standby)
• Storage Capacity: 4 GB excluding operating system, 480 MB for audio recording capacity |
|
|---|
|
|
|
|
|---|
|
|
● Ultra slim 1.5 mm can be hidden easily
● Wide working voltage range
● Built-in power protection circuit
● Low power consumption
● Simple connection
● Supports three recording modes
(Pre-book mode、Voice detection mode、Button mode)
● 3 hours working hour
● Customized card design |
|
|---|
|
|
|
● Meeting Recordings
● Interview Recordings
● Personal Reminders
● Language Learning
● Sound Collection
● Speech / Lecture Recordings
● On-the-Go Recordings
● Use AI Chat App to turn recorded voice into text
|
|
|---|
|
|
|
|---|
|
|
|
Product Safety and Compliance Standards
Cell ICP104648
Safty:EN 62386-1 ver3,EMC:EN55032 / EN55035 RoHS/WEEE
BSMI Cell UN38.3/Cell CNS15364,
Reader Safty CNS 15598-1/ EMC CNS15936
|
|
|---|
|
|
|
|
|---|
|
|
|
|
1/10.5" B/W CMOS 400p
Low Temperature (DVP Pin Define)
XP-B170M4-122
• Ø 4.6 x 6.5 mm
• Resolution: 400 x 400 @ 120 fps
• Pixel Size (um): 3.0 x 3.0
• Lens: 0.6 mm / F 2.1
• View Angle: 122° |
|
|---|
|
|
|
|
|---|
|
|
|
|
|
1/6" Color OS 1080p
Low Temperature (DVP Pin Define)
XP-B31105-77
• Ø 4.9 x 9.5 mm
• Resolution: 1920 x 1080 @ 15~30 fps
• Pixel Size (um): 1.4 x 1.4
• Lens: 1.83 mm / F 2.0
• View Angle: 77°
~ Coming Soon ~ |
|
|---|
|
|
|
|---|
|
|
Mini UVC Camera Module
2 Megapixel Camera |
|
|---|
|
B639B15U Series
1/2.8" Color CMOS camera with 1920 x 1080 @ 30 fps resolution.
MISUMI Mini Up View Camera module with excellent low-light sensitivity. |
|
|---|
|
|
|
|
1/2.8" Color CMOS 1080p
Low Temperature (USB 2.0)
XD-S639B15U-77
• 14.5 x 14.5 x 16.89 mm
• Resolution: 1920 x 1080 @ 30 fps
• Pixel Size (um): 2.9 x 2.9
• Lens: 4.14 mm / F 2.4
• View Angle: 77°
• Up View
|
|
|---|
|
|
|
|---|
|
|
B23703 Series
1/7.5" Color CMOS camera with 1500 x 1500 @ 60 fps resolution.
MISUMI Mini Camera module with excellent low-light sensitivity. |
|
|---|
|
|
1/7.5" Color CMOS 1500p
Low Temperature (USB 2.0)
XD-VBL23703LH-140
• 2.6 x 7.5 x 5.2 mm
• Resolution: 1500 x 1500 @ 60 fps
• Pixel Size (um): 1.116 × 1.116
• Lens: 0.763 mm / F 5.5 (Built-in)
• View Angle: 140° (Built-in)
• High-Intensity White LED x 4
~ Coming Soon ~
|
|
|---|
|
|
|
* Prototype. Final design/dimensions subject to change. |
|
|---|
|
|
|
|---|
|
|
B24604 Series
1/7.25" Color CMOS camera with 1920 x 1080 @ 30 fps resolution.
MISUMI Mini Camera module with excellent low-light sensitivity. |
|
|---|
|
|
1/7.25" Color CMOS 1080p
Low Temperature (USB 2.0)
XD-BL24602S-83
• Ø 4.0 x 17 (L) x 3.1 (H) mm
• Resolution: 1920 x 1080 @ 30 fps
• Pixel Size (um): 1.116 × 1.116
• Lens: 1.418 mm / F 4.7
• View Angle: 83°
46° / 55° / 81° / 83° / 88° / 95° / 120° / 139° (Optional)
• Single Board / Side View
|
|
|---|
|
|
|
1/7.25" Color CMOS 1080p
ISP on board (H.264 USB 2.0)
PD-S24608SU-88
• 8 (W) x 30.8 (L) x 2.85 (H) mm
• Resolution: 1920 x 1080 @ 30 fps
• Pixel Size (um): 1.116 × 1.116
• Lens: 1.25 mm / F 2.2
• View Angle: 88º
46° / 55° / 81° / 83° / 88° / 95° / 120° / 139° (Optional)
• Single Board / Up View
|
|
|---|
|
|
|
|---|
|
|
1/7.25" Color CMOS 1080p
Low Temperature (USB 2.0)
XD-TL24604LI-88
• Ø 4.7 x 20.5 mm
• Resolution: 1920 x 1080 @ 30 fps
• Pixel Size (um): 1.116 × 1.116
• Lens: 1.25 mm / F 4.7
• View Angle: 88°
46° / 55° / 81° / 83° / 88° / 95° / 120° / 139° (Optional)
• High-Intensity White LED x 1
• Side View |
|
|---|
|
|
|
1/7.25" Color CMOS 1080p
Advance (USB 2.0)
TD-SL246S4S-88
• 4 x 20 (L) x 2.35 (H) mm
• Resolution: 1920 x 1080 @ 30 fps
• Pixel Size (um): 1.116 × 1.116
• Lens:1.25 mm / F 2.2
• View Angle: 88°
46° / 55° / 81° / 83° / 88° / 95° / 120° / 139° (Optional)
• Single Board / Side View / FPC |
|
|---|
|
|
|
|---|
|
|
|
Competitive Advantages
Our professional R&D team has been applying state-of-the-art
technology to our quality products, and has enabled us to
take the lead over our competitors in design and innovation.
|
|
|---|
|
|
Refreshing Design
MISUMI has strong ability to adjust camera imaging parameter according to customers' needsor application environments.
|
|
|---|
|
|
Exclusive ISP
Our exclusive ISP is particularly designed for ultra mini cameras like no other.
|
|
|---|
|
|
|
|
Camera Shape Design
Camera shape and orientation can also
be tailor-made.
|
|
|---|
|
|
High-intensity LED (Patent)
Makes extremely mini size and enough illumination possible at the same time.
|
|
|---|
|
|
|
|
Specialized Cables
MISUMI is professional in transmitting long distance imaging signal through
our specialized cables.
|
|
|---|
|
|
Technical Experience
With over 38 years manufacture experience
and exceptional R&D team,
we are dedicated to develop and challenge innovation.
|
|
|---|
|
|
|
|
|---|
|
|
