General camera product code

1 - 2 3 4 - 5 - 6 7

Section 1
CMOS-analogy
MO Mini 4pin(male)
MJ Phone plug(D2.5mm)
MQ Waterproof 4pin(male)
MX Low light type-mini 4pin(male)
ED Rigid camera type (endoscope)
HS Hidden type
KO Wireless kit (included camera, transmitter, receiver)
KDO Wireless kit (included camera, transmitter, receiver)
AHD AHD signal-mini 4pin(male)
CVI CVI signal-mini 4pin(male)
TVI TVI signal-mini 4pin(male)
PVI PVI signal-mini 4pin(male)
CMOS-digital
MD USB 2.0 A type ( 2588 chip)
MM Micro USB OTG B type ( 2588 chip)
MT USB type C ( 2588 chip)
FD USB 2.0 A type and snapshot & freeze function ( 2588 chip)
FM Micro USB OTG B type and snapshot & freeze function ( 2588 chip)
FT USB type C (UVC) and snapshot & freeze function ( 2588 chip)
TD USB 2.0 A type ( 1688 chip)
TM Micro USB OTG B type ( 1688 chip)
TT USB type C ( 1688 chip)
FTD USB 2.0 A type (UVC) snapshot & freeze function ( 1688 chip)
FTM Micro USB OTG B type and snapshot & freeze function ( 1688 chip)
FTT USB type C (UVC) snapshot & freeze function ( 1688 chip)
HSD Hidden type(USB A connector)
HSM Hidden type(Micro USB OTG B type connector)
HST Hidden type(USB A connector)
EDD Rigid camera type (endoscope) and USB 2.0 A type connector

Section 2
B module type
BL module type(left side view)
T tube type
V tube type with LED and dimmer
S body type (built in epoxy resin)
SL body type side view(built in epoxy resin)
N Square type (hidden)
NS Small square type (hidden) with bracket
P Square type (plastic enclosure) with bracket
F Square type (iron enclosure) with bracket
Section 1 is "MO", camera connector will be RCA(male)/DC JACK (* available for Tube type)
L Snake type (with flexible iron pipe protect cable)
R Bullet type with bracket
M with motion detect function
W Waterproof type
FPC Flexible printed circuit camera

Section 3 - Camera series and camera size

Section 4
W 3 wires output
SW with thread on tube back (available for MO-T3506 series)
LW 4 wires output(with LED)
C Camera with cable length
Concealed lid (available for R5910C-3G, R5610C-3G )
LC Camera with cable length and LED
LSC Camera with cable length and LED and with thread on tube back(available for MO-T3506 series)
U Up view
D Down view
A with microphone
AG with microphone (MS-8300)
AD with microphone (MS-3300)
K Camera frame rate is fixed at 15 fps
KL Camera frame rate is fixed at 15 fps and with LED
E with OSD function(analogy), GPIO pin(digital)
J Camera frame rate is fixed at 60 fps (available for MD-T1003 series)
R Round type (available for MD-B31114, TD-B31109, TD-B20908)
S Straight cable (available for MD-N41xx series)
Q Spring cable (available for MD-N41xx series)

Section 5 - Lens code which is used in the camera
Section 6 - Camera system (NTSC/PAL or EIA/CCIR) available for analogy series
Section 7 - Custom camera by serial number
NOTE: some might not fit the general code meaning

General lens product code

1 2 3 4 - 5 - 6

Section 1 -Types of lens or pixel (pin hole / board / megapixel)

L G type lens, Board Lens
LP Pin hole lens
1M 1 Megapixel Lens
2M 2 Megapixel Lens
3M 3 Megapixel Lens
5M 5 Megapixel Lens
8M 8 Megapixel Lens
12M 12 Megapixel Lens
Section 2 -Focal length (mm)
Section 3 -Aperature (F)
Section 4 -Lens coating (AR/IR)
Section 5 -Lens mount/size (Mxx)
Section 6 -Custom lens by serial number
NOTE: some might not fit the general code meaning

General cable accessary code

1 - 2 3 4 5 - 6

Section 1 -Cable types(AF-XXXXX)
Section 2 -Total cable length (three digits)
Section 3 -Front side connector
Section 4 -End side connector
Section 5 -Second end side connector (if needed)
Section 6 -Serial number
NOTE: some might not fit the general code meaning


Basic information for your reference

• Camera with LED light source are suggested to use with large aperture  F number
• FID: AA-BB-CC mm
   FID means focus distance Identification
   AA means the clearest point
   BB-CC means the range that still can be seen
   For example: 50-20-70mm
   50mm is the focus point and 20mm to 70mm is the range of viewing distance.

• Cameras with UTC function can use with UTC controller (model: UTC-100) to adjust image display.
   UTC-100 can be purchased separately.

• Camera orientation types:

camera viewing direction


• Binning VGA vs. Crop VGA:
Binning VGA vs. Crop VGA
