▪ Support for black sun cancellation
▪ IR 850nm LED x 10
▪ Pixel size: 4.2um(H) x 4.2um(V)
▪ Pixel: 640 x 480
▪ 450 TV Lines
▪ 0.03 Lux / 98IRE, 15 fps-LED turn off
▪ Frame rate: 15 & 30 fps (auto)
▪ Dynamic range: 71 [dB]
▪ S/N ratio: 38 [dB]
▪ Power: DC 5~12V (MX-T95408)
▪ Dimensions(mm): (D)7.8 (MX-T87408)

1/3" Color CCIQ II Camera MX-B5609-4F, MX-B5609-4H

▪ 1/3" Color CCIQ III (MX-B5609, MX-B5609K)
▪ 728(H) x 488(V)
▪ Pixel size: 6 um x 6 um
▪ Resolution: 480 TV lines
▪ 0.03 Lux / 50IRE, 15 fps-LED turn off / 60cm)
▪ 0.03 Lux / 140IRE, 15 fps-LED turn on / 60cm)
▪ Frame rate:
30 fps(NTSC-EIA), 25 fps(PAL-CCIR) (MX-B5609)
15 fps(NTSC-EIA & PAL-CCIR) (MX-B5609K)
▪ Sensitivity: 13.8 [V/Lux.sec]
▪ Dynamic range: 63.7 [dB]
▪ S/N ratio: 46.4 [dB]
▪ Lens: 4.5mm/F2.8(4H Lens), 4.0mm/F2.0(4F Lens), 3.6mm/F2.0(3G2 Lens-Micro board Lens)
▪ Focal distance: infinity
▪ Power: DC3.3V
▪ Dimensions(mm): (D)8.8

1/2" Color CMOS Star Light Camera MX-B8832-7818, MX-B7732-6018, MX-B8823, MX-B7723

Hybrid sensitivity Super low light camera !!/ ECO Friendly
▪ 1/2" Hybrid sensitivity color & B/W camera
▪ Pixel size: 8.60um(H) x 8.30um(V)
▪ Pixel: 768H x 582V
▪ 0.01 lux / F1.2 83 IRE
▪ Frame rate: 5~30 fps
▪ Shutter Type: Electronic Rolling
▪ Dynamic range: 69 [dB]
▪ S/N ratio: 48 [dB]
▪ Power: DC 5 ~12V (5V/360mA; 12V/150mA)

MX-B8832
▪ Dimensions(mm): 32 x 32

MX-B8823
▪ Dimensions(mm): 23(D) x 38.5

1/3.7" CCIQIII Hybrid sensitivity camera MX-B5509 series

▪ Hybrid sensitivity concealed camera !!
▪ 1/3.7" Hybrid sensitivity color or B/W camera
▪ Pixel: 648(H) x 488(V)
▪ Resolution: 550 TV Lines(B/W), 480 TV Lines (color)
▪ 0.03 Lux / 50IRE, 15 fps-LED turn off / 60cm)
▪ 0.03 Lux / 140IRE, 15 fps-LED turn on / 60cm)
(0.5 Lux / 74.5IRE, 15 fps), (0.5 Lux / 63.2IRE, 30 fps)
▪ Frame rate:
30 fps(NTSC-EIA), 25 fps(PAL-CCIR)(MO-B5509, MO-B5709)
15 fps(NTSC-EIA & PAL-CCIR)(MO-B5509K, MO-B5709K)
▪ Sensitivity: 8.2 [V/Lux.sec]
▪ Dynamic range: 63.3 [dB]
▪ S/N ratio: 47 [dB]
▪ Power: DC 3.3V (160mA- max)
▪ Dimension(mm): (D)8.8 x 16.2
▪ If you have customized camera designs(15 fps~1fps), Misumi can help you realize them. Feel free to send us your ideas, and we can help custom build your special camera application.

Environment: 0.1 Lux | Frame rate: 15 fps | LED: IR 940 nm x 4

1/2" Color MCCD Digital Hybrid Sensitivity Camera Board MX-B8823, MX-B7723, MX-B8832, MX-B7732

Hybrid sensitivity Super low light camera !!/ ECO Friendly
▪ 1/2" Hybrid sensitivity color & B/W camera
▪ Pixel size: 8.60um(H) x 8.30um(V)
▪ Pixel: 768H x 582V
▪ 0.01 lux / F1.2 83 IRE
▪ Frame rate: 5~30 fps
▪ Shutter Type: Electronic Rolling
▪ Dynamic range: 69 [dB]
▪ S/N ratio: 48 [dB]
▪ Lens: 7.8mm/F1.8
▪ Power: DC 5 ~12V (5V/360mA ; 12V/150mA)

MX-B8832
▪ Dimension(mm): 32x32

MX-B8823
▪ Dimension(mm): 23(D)x38.5

1/3.7" Color CMOS Camera MX-T95710KL-43F, MX-T65510KL-43F, MX-T95710KLX-43F, MX-T95708KL-43F

• Hybrid sensitivity Super low light camera!!
▪ IR 940nm LED
▪ 1/3.7" Hybrid sensitivity color or B/W
▪ Pixel: 648(H) x 488(V)
▪ Resolution: 550 TV Lines(B/W), 480 TV Lines(color)
▪ 0.03 Lux / 50IRE, 15 fps-LED turn off / 60cm)
0.03 Lux / 140IRE, 15 fps-LED turn on / 60cm)
▪ Frame rate: 15 fps
▪ Sensitivity: 8.2 [V/Lux.sec]
▪ Dynamic range: 63.3 [dB]
▪ S/N ratio: 47 [dB]
▪ Lens: 4.3mm/F2.0
▪ Power: DC 5 ~12V, 80mA (max)
▪ Dimensions(mm):
(D)10 x 30 (MX-T95710 series)
(D)8.5 x 27.5 (MX-T95708 series)
Low light camera, dark helper

1/2" B/W MCCD Digital Hybrid Sensitivity Camera Board MX-B7723

▪ Hybrid sensitivity Super low light camera !!/ ECO Friendly
▪ Pixel size: 8.60um(H) x 8.30um(V)
▪ Pixel: 768H x 582V
▪ 0.01 lux / F1.2 83 IRE
▪ Frame rate: 5~30 fps
▪ Shutter Type: Electronic Rolling
▪ Dynamic range: 69 [dB]
▪ S/N ratio: 48 [dB]
▪ Power: DC 5 ~12V (5V/360mA ; 12V/150mA)
▪ Dimension(mm): (D)23 x 38.5

1/2" B/W MCCD Digital Hybrid Sensitivity Camera Board MX-B7732

▪ Hybrid sensitivity Super low light camera !!/ ECO Friendly
▪ Pixel size: 8.60um(H) x 8.30um(V)
▪ Pixel: 768H x 582V
▪ 0.01 lux / F1.2 83 IRE
▪ Frame rate: 5~30 fps
▪ Shutter Type: Electronic Rolling
▪ Dynamic range: 69 [dB]
▪ S/N ratio: 48 [dB]
▪ Lens: 7.8mm/F1.8
▪ Power: DC 5 ~12V (5V/360mA ; 12V/150mA)
▪ Dimension(mm): 32x32

1/3.7" CCIQIII Hybrid sensitivity monochrone camera MX-B5709-4H, MX-B5709K-4H

▪ Hybrid sensitivity concealed camera !!
▪ Pixel: 648(H) x 488(V)
▪ Resolution: 550 TV Lines
▪ 0.03 Lux / 50IRE, 15 fps-LED turn off / 60cm)
▪ 0.03 Lux / 140IRE, 15 fps-LED turn on / 60cm)
(0.5 Lux / 74.5IRE, 15 fps), (0.5 Lux / 63.2IRE, 30 fps)
▪ Frame rate:
30 fps(EIA), 25 fps(PCCIR)
15 fps(EIA & CCIR)(MO-B5709K)
▪ Sensitivity: 8.2 [V/Lux.sec]
▪ Dynamic range: 63.3 [dB]
▪ S/N ratio: 47 [dB]
▪ Lens: 4.5mm/F2.8
▪ Power: DC 3.3V (160mA- max)
▪ Dimension(mm): (D)8.8 x 16.2
▪ If you have customized camera designs(15 fps~1fps), Misumi can help you realize them. Feel free to send us your ideas, and we can help custom build your special camera application.

Environment: 0.1 Lux | Frame rate: 15 fps | LED: IR 940 nm x 4

1/3.7" Color CMOS Camera MX-T95710KL-43F,MX-T65510KL-43F, MX-T95710KLX-43F, MX-T95708KL-43F

Hybrid sensitivity Super low light camera !!
▪ IR 940 nm LED
▪ 1/3.7" Hybrid sensitivity color or B/W
▪ Pixel: 648(H) x 488(V)
▪ Resolution: 550 TV Lines(B/W), 480 TV Lines (color)
▪ 0.03 Lux / 50IRE, 15 fps-LED turn off / 60cm)
0.03 Lux / 140IRE, 15 fps-LED turn on / 60cm)
▪ Frame rate: 15 fps
▪ Sensitivity: 8.2 [V/Lux.sec]
▪ Dynamic range: 63.3 [dB]
▪ S/N ratio: 47 [dB]
▪ Lens: 4.3mm/F2.0
▪ Power: DC 5 ~12V (80mA- max)
▪ Dimension(mm):
(D)10x30 (MX-T95710 series)
(D)8.5x27.5 (MX-T95708series)
Low light camera, dark helper

1/2" Color CMOS Low Light Camera C/CS Mount type camera module MX-B8832-N02 MX-B7732-N02 MX-B8832-P02 MX-B7732-P02

C/CS Mount type camera module
Hybrid sensitivity Super low light camera !!/ ECO Friendly
▪ 1/2" Hybrid sensitivity color & B/W camera
▪ Pixel size: 8.60um(H) x 8.30um(V)
▪ Pixel: 768H x 582V
▪ 0.01 lux / F1.2 83 IRE
▪ Frame rate: 5~30 fps
▪ Shutter Type: Electronic Rolling
▪ Dynamic range: 69 [dB]
▪ S/N ratio: 48 [dB]
▪ Power: DC 5 ~12V (5V/360mA; 12V/150mA)

MX-B8832, MX-B7732
▪ Dimensions(mm): 32 x 32

MX-B8823, MX-B7723
▪ Dimensions(mm): 23(D) x 38.5

1/3.7" CCIQIII Hybrid sensitivity camera MX-R5512-4K , MX-R5712-4K

Hybrid sensitivity low light intensive camera !!
▪ Model: MX-R5512-4K(color) , MX-R5712-4K(B/W)
▪ 1/3.7" Hybrid sensitivity Camera
▪ Pixel: 648(H) x 488(V)
▪ Resolution: 480 TV Lines
▪ 0.03 Lux / 50IRE, 15 fps-LED turn off / 60cm)
▪ 0.03 Lux / 140IRE, 15 fps-LED turn on / 60cm)
▪ Frame rate: 30 fps(NTSC/EIA), 25 fps(PAL/CCIR); 15 fps(NTSC & PAL)
▪ Sensitivity: 8.2[V/Lux.sec]
▪ Dynamic range: 63.3 [dB]
▪ Lens: 4.25mm/F1.1
▪ Power: DC 5 ~12V, 80mA (max)

If you have customized camera designs(15 fps~1fps), Misumi can help you realize them. Feel free to send us your ideas, and we can help custom build your special camera application.

1/4" Color CCIQ Camera MO-R5012L9-4FY

▪ High image quality and Ultra low light performance
▪ UTC Control function
▪ Mini size
▪ with high power IR 940nm LED
▪ Effective pixel array: 712 x 552 (640 x 480 output pixel array)
▪ Pixel size: 5.6 um x 5.6 um
▪ Effective image area: 3.99 mm x 3.09 mm x 5.0 mm
▪ Resolution: 480 TV Line
▪ Sensitivity: 16 [V/Lux.sec]
▪ SNR: 44.8 [dB]
▪ Dynamic range: 75 [dB]
▪ Power: DC 5~12 V
▪ Dimension(mm): 12(D)x30
